Formax AutoSeal® FD 2056 Tabletop Pressure Sealer

The AutoSeal® FD 2056 is a fully automatic pressure sealer designed to streamline your post-processing tasks. Ideal for high-volume environments, this advanced tabletop solution processes pressure-sensitive one-piece mailers with exceptional efficiency and ease of use.

Key Features:

• High-Speed Processing: Handles up to 16,450 forms per hour for rapid job completion.
• Color Touchscreen Interface: Large, full-color touchscreen for intuitive operation.
• Drop-In Feed System: Reliable three-roller feed system eliminates the need for paper fanning.
• 17” Form Capability: Processes forms up to 17” in length, providing flexibility.
• AutoStack™ Wheels: Automatically adjusts stacker wheels for different form sizes and fold types.
• Integrated Telescoping Conveyor: Adjustable length conveyor holds up to 500 folded pieces.
• Noise Reduction: Insulated covers and enclosed fold plates reduce operating noise.
• Fault Detector: Identifies double feeding and other issues.
• Counters: Includes 6-digit resettable and 8-digit life counters for audit control.
• AutoBatch™ Counter: Programmable to process a set number of forms with a delay.

Folding Features:

• Preset Folds: Pre-programmed for 5 popular fold types in 11-17” forms and uneven C and Z in 14” forms.
• Custom Folds: Stores up to 35 custom folds in memory.
• Adjustable Fold Settings: Modify preset fold types for maximum flexibility and customization.

Technical Features:

• Adjustable Feed Table Pressure: Seven positions to adjust hopper tension for different paper stocks.
• Seven-Point Fold Stops: Ensures precise, accurate folds for large paper sizes at high speeds.
• Removable Roller Cover: Easy access to sealer rollers and exit area.
• Easy-Off Feed Wheel Shaft: Quick change of feed wheels without removing side covers.

Options:

• Locking Cabinet: Fully enclosed for secure storage.
• 402 Series Jogger: Reduces static electricity and aligns forms for proper feeding.
• V-Stack36i Stacker: Vertically stacks up to 22” of folded documents for easy unloading.

Specifications:

• Speed: Up to 16,450 forms per hour
• Hopper Capacity: Up to 500 forms (20#)
• Pre-Set Folds: C, V, Z, and uneven C and Z
• Custom Folds: Stores up to 35 custom folds
• Paper Size: Min: 3.5” W x 5” L, Max: 12.25” W x 18” L
• Dimensions: Closed: 43” L x 21.28” W x 16” H, Fully Extended: 55” L x 21.28” W x 16” H
• Weight: 127 lbs
• Power: 110-240VAC 50/60 Hz
• Safety Certifications: UL & CE applied for
• Made in the USA
