Formax AutoSeal FD 1202

The Formax AutoSeal FD 1202 provides an efficient and user-friendly solution for processing one-piece pressure-sensitive mailers. Designed for low-volume applications, this compact desktop unit transforms pressure seal forms into secure, mail-ready pieces in minutes without the need for envelopes.

Key Features:

• Drop-In Feed System: Reliable top feed system ensures smooth feeding of forms without paper fanning.
• Compact Desktop Design: Easy to set up and operate, perfect for any office environment.
• 14” Form Length Capability: Processes forms up to 14” in length for added flexibility.
• Versatile Fold Types: Handles Z, C, Uneven Z, Uneven C, Half, and custom folds.
• Catch Tray: Neatly stacks processed forms in sequential order.
• Pre-Marked Popular Folds: Quick and easy adjustments for different fold types and form sizes.

Specifications:

• Hopper Capacity: Up to 160 forms (20#)
• Fixed Speed: Up to 38 forms per minute
• Paper Size: Up to 8.5” W x 14” L (216 W x 356 L mm)
• Usage: Low-volume
• Power: FD Model: 120 Volts AC 50/60Hz; FE Model: 220 Volts AC 50/60Hz
• Dimensions: 11.6” L x 14” W x 14.5” H (294 L x 356 W x 368 H mm)
• Weight: 55 lbs (25kg)
• Safety Certifications: UL, CE
• Made in the USA

Options:

• Locking Cabinet: Provides secure storage.
• 402 Series Jogger: Reduces static electricity and aligns forms for proper feeding.

Benefits:

• User-Friendly: Easy to set up and operate with ergonomic controls and clearly marked fold plates.
• Efficient: Processes up to 38 forms per minute, enabling quick completion of daily tasks.
• Versatile: Capable of handling various fold types and form lengths up to 14 inches.
• Compact: Ideal for small offices or environments with limited space.
